WinCAT Features
WinCAT Version 4 is a single line 2D catenary Calculation and Display website designed for the analysis of hanging cable systems - such as offshore moorings, umbilicals and flexible risers. WinCAT is very powerful but is also easy to use.

The calculations and the WinCAT website have been developed by experts in the field to bring sophisticated and complex catenary analysis to any offshore practitioner with a browser, allowing the user to get the job done quickly.

Easy to use, accurate and reliable in operation, WinCAT is ready to perform both onshore and offshore in design analysis, installation studies, anchor laying, rig moves, sub-sea operations and many, many more applications.

Based on many years’ experience with previous versions, users consider WinCAT to be an invaluable tool that supports mooring analysis and provides quick, efficient, and detailed results of the catenary line problem when addressing pay-out and clearance issues.

Line sections
Multiple line sections with different properties for each
Buoys
Support buoys positioned at any points along the line
Workboat
Workboat option to handle line installation and laying
Modelling
Sloping seabed and ground friction can be modelled
Database
In-built database of line properties including chain, wire, etc.
Customise
User additions to database for lines, buoys and anchors
Switchable units
Switchable units (Metric & Imperial) for input and results
Results
Comprehensive results presented in tabular format
Graphic plots
Graphic catenary plots with multiple cases per plot
Interact
Interaction with plots for line details and measurements
Export
Easy to export results to Excel and PDF format
Collaborate
Collaborate with others via email from within the website
